MTK9679 Android 14.0 Interactive Flat Panel
55inch/65inch/75inch/86inch/98inch 4K Interactive Flat Panel Display
* Ultra HD display with up to 3840*2160 resolution of input signal available.
* 20px ultra fine writing, and 2mm diameter recognizable with the precision of 1 mm.
* Built-in Wi-Fi realizes miracasting without any cable connection.
* Built-in interactive whiteboard system allows annotating and sharing by QR code.
* Looping-out display available.
* Various audio and video interfaces for device access.
* Built-in Android system provides kinds of applications.
* Compatible with OPS/OPS-C devices, realizing smooth switch between built-in systems.
* Ultra-thin design with aluminum profile frame.
* Ultra HD display with up to 3840*2160 resolution of input signal available.
* 20px ultra fine writing, and 2mm diameter recognizable with the precision of 1 mm.
* Built-in Wi-Fi realizes miracasting without any cable connection.
* Built-in interactive whiteboard system allows annotating and sharing by QR code.
* Looping-out display available.
* Various audio and video interfaces for device access.
* Built-in Android system provides kinds of applications.
* Compatible with OPS/OPS-C devices, realizing smooth switch between built-in systems.
* Ultra-thin design with aluminum profile frame.
| Active Screen Size ("inch) | 55" | 65" | 75" | 86" | 98" |
| Display Backlight | LED | LED | LED | LED | LED |
| Display Area (Horizontal * Vertical) | 1209.6(H)×680.4(V) | 1428.48(H) ×803.52(V) | 1649.664(H) ×927.936(V) | 1895.04(H) × 1065.96(V) | 2158.8(H)×1214.4(V) |
| Resolution | 3840*2160 Pixel (2K/4K) | 3840*2160 Pixel (4K) | 3840*2160 Pixel (4K) | 3840*2160 Pixel (4K) | 3840*2160 Pixel (4K) |
| Display Colors | 1.07G,10 bit | 1.07G,10 bit | 1.07G,10 bit | 1.07G,10 bit | 1.07G,10 bit |
| AG Glass | yes | yes | yes | yes | yes |
| LCD Brightness | 450cd/m2 | 450cd/m2 | 450cd/m2 | 450cd/m2 | 450cd/m2 |
| Contrast Ratio (Typical) | 5000:1 | 5000:1 | 5000:1 | 5000:1 | 5000:1 |
| Response Time (Typical) | 8ms | 8ms | 8ms | 8ms | 8ms |
| Viewing Angle | 178∘ | 178∘ | 178∘ | 178∘ | 178∘ |
| Life time (working hours/day) | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours |
| Power Consumption | <=250W | <=250W | <=300W | <=400W | <=400W |
| Working Voltage | AC 100-240V, 50/60Hz | AC 100-240V, 50/60Hz | AC 100-240V, 50/60Hz | AC 100-240V, 50/60Hz | AC 100-240V, 50/60Hz |
| Touch Surface Material | Tempered glass | Tempered glass | Tempered glass | Tempered glass | Tempered glass |
| Super Narrow Bezel | 12mm | 12mm | 12mm | 12mm | 12mm |
| Anti glare | yes | yes | yes | yes | yes |
| Touch Surface Hardness | >H7 | >H7 | >H7 | >H7 | >H7 |
| Touch Surface Thickness | 4mm | 4mm | 4mm | 4mm | 4mm |
| Touch Points | 20 Points under Android/40 Points(Windows) | 20 Points under Android/40 Points(Windows) | 20 Points under Android/40 Points(Windows) | 20 Points under Android/40 Points(Windows) | 20 Points under Android/40 Points(Windows) |
| Cursor Speed | 180Point/s | 180Point/s | 180Point/s | 180Point/s | 180Point/s |
| Positioning Accuracy | ±2mm | ±2mm | ±2mm | ±2mm | ±2mm |
| Recognition distance | ≤1mm | ≤1mm | ≤1mm | ≤1mm | ≤1mm |
| Speaker Position | 2 | 2 | 2 | 2 | 2 |
| Speaker Max.Power Output | 15W*2 | 15W*2 | 15W*2 | 15W*2 | 15W*2 |
| Subwoofer | Yes | Yes | Yes | Yes | Yes |
| Lightning sensor/Brightness auto adjusting | optional | optional | optional | optional | optional |
| Outline Dimension (without wall mount bracket thickness) | 1257*755*840(mm) | 1486*924*102 (mm) | 1713*1054*105 (mm) | 1959*1193*102 (mm) | 2218.4*1306.7*93.2(mm) |
| Net Weight | 32kg | 37kg | 56,5kg | 70kg | 115kg |
| CPU | Mediatek 9679 Cortex-A73 | Mediatek 9679 Cortex-A73 | Mediatek 9679 Cortex-A73 | Mediatek 9679 Cortex-A73 | Mediatek 9679 Cortex-A73 |
| GPU | Mali G52-MC1 | Mali G52-MC1 | Mali G52-MC1 | Mali G52-MC1 | Mali G52-MC1 |
| RAM | 8G | 8G | 8G | 8G | 8G |
| ROM | 128G | 128G | 128G | 128G | 128G |
| Android Version | 14 | 14 | 14 | 14 | 14 |
| Chrome,Google playstore is available | yes | yes | yes | yes | yes |
| Built-in WIFI | 2.4G/5G wireless network, wired network， Bluetooth | 2.4G/5G wireless network, wired network， Bluetooth | 2.4G/5G wireless network, wired network， Bluetooth | 2.4G/5G wireless network, wired network， Bluetooth | 2.4G/5G wireless network, wired network， Bluetooth |
| Stylus | 2 pens | 2 pens | 2 pens | 2 pens | 2 pens |
| Wall mount | yes | yes | yes | yes | yes |
| Front interfaces | USB TOUCH*1 HDMI 2.0 *1 USB 2.0*2 USB 3.0*1 TYpe C | USB TOUCH*1 HDMI 2.0 *1 USB 2.0*2 USB 3.0*1 TYpe C | USB TOUCH*1 HDMI 2.0 *1 USB 2.0*2 USB 3.0*1 TYpe C | USB TOUCH*1 HDMI 2.0 *1 USB 2.0*2 USB 3.0*1 TYpe C | USB TOUCH*1 HDMI 2.0 *1 USB 2.0*2 USB 3.0*1 TYpe C |
| Rear interfaces | 2*RJ45 1*RS232 1*OPTICAL OUT 1*MIC IN 1*LINE OUT 1*USB 3.0 1*USB 2.0 1*TOUCH USB 2*HDMI IN | 2*RJ45 1*RS232 1*OPTICAL OUT 1*MIC IN 1*LINE OUT 1*USB 3.0 1*USB 2.0 1*TOUCH USB 2*HDMI IN 1*VGA | 2*RJ45 1*RS232 1*OPTICAL OUT 1*MIC IN 1*LINE OUT 1*USB 3.0 1*USB 2.0 1*TOUCH USB 2*HDMI IN | 2*RJ45 1*RS232 1*OPTICAL OUT 1*MIC IN 1*LINE OUT 1*USB 3.0 1*USB 2.0 1*TOUCH USB 2*HDMI IN | 2*RJ45 1*RS232 1*OPTICAL OUT 1*MIC IN 1*LINE OUT 1*USB 3.0 1*USB 2.0 1*TOUCH USB 2*HDMI IN |
| Front panel buttons | 1 button | 1 button | 1 button | 1 button | 1 button |
| Microphone for optional | 8array | 8array | 8array | 8array | 8array |
| Camera for optional | 48MP | 48MP | 48MP | 48MP | 48MP |
| Panel | Original Grade A | Original Grade A | Original Grade A | Original Grade A | Original Grade A |
